Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Bore (in):
    3.82
  • Stroke (in):
    4.45
  • Displacement (cc):
    1670
  • Carburetion Brand:
    Mikuni
  • Fuel Injector:
    No
  • Carburetor:
    Yes
  • Number Of Carburetors:
    1
  • Carburetion Type:
    Carburetor
  • Turbocharged:
    No
  • Supercharged:
    No
  • Compression ratio:
    8.3:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Belt
  • Gear Ratio (1):
    2.375
  • Gear Ratio (2):
    1.579
  • Gear Ratio (3):
    1.16
  • Gear Ratio (4):
    0.906
  • Gear Ratio (5):
    0.75
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    98.4
  • Width (in):
    38.6
  • Height (in):
    59.1
  • Wheelbase (in):
    66.5
  • Ground Clearance (in):
    5.7
  • Dry Weight (lbs):
    721
  • Fuel Capacity (gal):
    5.3
  • Engine Displacement to Weight (cc):
    2.32
  • Turning Radius (ft):
    10.5
  • Fuel Capacity Reserve (gal):
    0.9
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    5.5
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    4.3
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Tire Brand:
    Bridgestone®
  • Front Tire (Full Spec):
    130/90 HR16
  • Front Wheel Width (in):
    3
• BRAKES

  add remove
  • Front Brake Type:
    Dual Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    12.6
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    28
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Standard
  • Seat Backrest:
    Standard
  • Grab Rail or Strap:
    Standard
  • Backrest Location:
    Passenger
  • Backrest Type:
    Detachable
  • Backrest Logo Plate:
    No
  • Lumbar Adjustment:
    No
