Specifications

• Dimensions

  add remove
  • Length:
    105.1 in
  • Seat height, unladen:
    28.9 in
  • Ground clearance:
    4.9 in
  • Rake (steering head):
    26
  • Trail:
    3.9 in
  • Wheelbase:
    65.7 in
  • Tires, front specifications:
    MT90B16 72H
  • Tires, rear specifications:
    P205/65R15 92T
  • Fuel Capacity:
    6.0 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    1,204 lbs
  • Weight, in running order:
    1243 lb
  • Luggage capacity – volume:
    6.8 cu ft (0.19 m3)
• Engine

  add remove
  • Engine:
    Twin-Cooled™ Milwaukee-Eight® 114
  • Bore:
    4.0 in
  • Stroke:
    4.5 in
  • Displacement:
    113.99 in³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-1-2 dual exhaust with tapered mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    117.3 ft-lb
  • Engine torque (RPM):
    3250
  • Lean angle, right (deg.):
    N/A
  • Lean angle, left (deg.):
    N/A
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    0.00 mpg
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions :
    158 g/km CO2
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    10.534
  • Gear ratios (overall) 2nd:
    7.302
  • Gear ratios (overall) 3rd:
    5.423
  • Gear ratios (overall) 4th:
    4.392
  • Gear ratios (overall) 5th:
    3.741
  • Gear Ratios (overall) 6th:
    3.157
• Chassis

  add remove
  • Wheels, front type:
    Black, 7-spoke Cast Aluminum
  • Wheels, rear type:
    Black, 7-spoke Cast Aluminum
  • Brakes, caliper type:
    Front: 32mm 4 piston fixed, Rear: floating 36mm piston integrated park brake
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High Beam, running lights, front fender running lights, directional lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, security system, low fuel warning, reverse, park brake, fog/aux lamp indicator
  • Gauges:
    Speedometer, tachometer, fuel, and voltage gauges; display features odometer, trip A, trip B, range to empty, gear indicator
• Infotainment

  add remove
  • Infotainment system:
    Boom!™ Box GTS
  • Type:
    Full Color TFT
  • Watts per channel:
    25
  • Speakers:
    4
  • Speaker size:
    5.25 inch/6.5 inch P&A Upgrade
  • Headset specifications (if equipped):
    16 - 64 ohms
  • AM:
    Standard
  • FM:
    Standard
  • Weather Band (WB):
    Standard
  • SD Card, Flash Drive and MP3 — via USB Connection:
    Supported
  • Sirius^XM Presets:
    20 - P&A Upgrade (USA & Canada only)
  • Languages:
    English (US/UK) German Spanish (Mexico/Spain) French (Canada/France) Italian Portuguese (Portugal/Brazil) Russian Czech Polish Dutch Turkish Japanese Korean Chinese (Simplified) Siamese (Thai) Bahasa (Indonesian) Arabic
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    English (US/UK) German Spanish (Mexico/Spain) French (Canada/France) Italian Portuguese (Portugal/Brazil) Russian Czech Polish Dutch Turkish Japanese Korean Chinese (Simplified) Siamese (Thai) Bahasa (Indonesian) Arabic
  • Voice Recognition Languages: Tuner / Media / Navigation:
    English (US/UK) German Spanish (Mexico/Spain) French (Canada/France) Italian Portuguese (Portugal/Brazil) Russian Czech Polish Dutch Turkish Japanese Korean Chinese (Simplified) Siamese (Thai) Bahasa (Indonesian) Arabic
  • Text-to-Speech (TTS) languages:
    English (US/UK) German Spanish (Mexico/Spain) French (Canada/France) Italian Portuguese (Portugal/Brazil) Russian Czech Polish Dutch Turkish Japanese Korean Chinese (Simplified) Siamese (Thai) Bahasa (Indonesian) Arabic
  • Rider / passenger intercom:
    Standard
  • Vehicle information screen:
    Standard
  • USB:
    USB/MTP/iPod/iPhone
  • Bluetooth:
    Phone/Media Supported
