The 2026 Road Glide Limited sets the new standard for long-haul touring built for two. The Milwaukee-Eight® VVT 117 motor delivers unstoppable power, while heated seats, an all-new Grand Tour-Pak® with flush lighting, and a four-speaker, 200-watt audio system turn every mile into a story you and your passenger can share forever. This is as good as two-up touring gets.

Specifications

  • Dimensions
    add remove
    • Length:
      103.1 in
    • Seat height, unladen:
      29.1 in
    • Rake (steering head):
      26
    • Wheelbase:
      64.0 in
    • Tires, front specifications:
      130/60B19 M/C 61H
    • Tires, rear specifications:
      180/55B18 M/C 80H
    • Oil capacity:
      5 qt.
    • Weight, as shipped:
      882 lbs
    • Weight, in running order:
      919 lb
    • Luggage capacity – volume:
      5.05 cu ft (0.143 m3)
  • Engine
    add remove
    • Engine:
      Milwaukee-Eight® VVT 117
    • Bore:
      4.1 in
    • Stroke:
      4.5 in
    • Displacement:
      117.35 in3
    • Compression ratio:
      10.3:1
    • Fuel system:
      Electronic Sequential Port Fuel Injection (ESPFI)
    • Exhaust:
      2-1-2 dual exhaust with tapered mufflers
  • Performance
    add remove
    • Engine torque testing method:
      J1349
    • Engine torque:
      130.5 ft-lb
    • Engine torque (RPM):
      3250
    • Horsepower:
      106 HP / 79 kW @ 4600 rpm
    • Fuel economy testing method:
      Estimated City/Hwy
    • Fuel economy:
      45 mpg (5.1 l/100 km)
  • Powertrain
    add remove
    • Primary drive:
      Belt, 32/68 ratio
    • Gear ratios (overall) 1st:
      9.593
    • Gear ratios (overall) 2nd:
      6.65
    • Gear ratios (overall) 3rd:
      4.938
    • Gear ratios (overall) 4th:
      4
    • Gear ratios (overall) 5th:
      3.407
    • Gear Ratios (overall) 6th:
      2.875
  • Chassis
    add remove
    • Front fork:
      1.9 in Dual Bending Valve
    • Rear shocks:
      3 in Dual adjustable emulsions suspension with remote preload adjustment on the left shock, and threaded preload on the right shock
    • Wheels, front type:
      Cast aluminum
    • Wheels, rear type:
      Cast aluminum
    • Brakes, type:
      Dual floating rotors (front), fixed rotor (rear)
    • Brakes, caliper type:
      1.3 in, 4-piston fixed dual axially mounted front, and single axially mounted rear
  • Infotainment
    add remove
    • Infotainment system:
      Skyline™ OS
    • Type:
      Full Color TFT
    • Watts per channel:
      50
    • Speakers:
      4
    • Speaker size:
      Two 6.5 in fairing speakers plus two 6.5 in Tour-pak speakers
    • AM:
      Standard
    • FM:
      Standard
    • SD Card, Flash Drive and MP3 — via USB Connection:
      Supported
    • Languages:
      Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese
    • Hands-free mobile phone — via Bluetooth:
      Standard
    • Voice Recognition Languages: Phone functions only:
      Phone dependent
    • Voice Recognition Languages: Tuner / Media / Navigation:
      Danish, English (UK/USA default), French (Canada/France), German, Italian, Spanish (Mexico/Spain) & Swedish
    • Text-to-Speech (TTS) languages:
      Same as Languages list
    • Vehicle information screen:
      Standard
    • USB:
      USB-C/MTP/Smartphone will work with any phone which has proper adapters to the connection located in the inner fairing storage
    • Bluetooth:
      Phone/Media Player, Headset
